The Gosford light fitting has an opal bullet lens, made from polyethylene.
The body and reflector are spun aluminium. Available side or top entry
GSL550
Models
Gosford Lantern
Dimensions
H:550mm x 380mm
Category: Post Tops
Geneva Pillar Light
The medium Geneva piller mounting fixture, matches up with the post top,
it is supplied with an es lamp holder.
G/62/EPM/CLAW Piller Fixing
also can be wall mounted
Is available in most Colours
Dimensions
H 770 x W 370
AL-653
P65 Rated
Die cast aluminium Body
Powdercoat finish Black
40 watt
Colour Temperature 4000K
76mm Spigot
Lumen Output 4,400LM
Part Number AL-653-40L
Material Specification
Body: Die Cast Aluminium
Colours: Black, Grey, White
Cover: UV Resistant Polycarbonate
Gasket: Silicone gasket
Fasteners: Socket HDC stainless stell
Ingress Protection: IP65
Impact Protection: IK08
General Specification
Application: Parks, Outdoor Lighting
Dimensions: 653 x 544
Warranty: 5 Year conditional warranty standard
Optics: 182.1
Working Environment: -30 – +50, 20% -90%
Lifespan: 80, 000
Electrical Specification
Fixture Luminous Flux (lm): 2828 @ 4000K
Luminaire efficacy (lm/W): 70.7
Input Voltage: AC 100-277V
Power Supply: Meanwell
Power Factor: >=0.9
SPD: 10KV (built in driver) / Extra 10KV SPD (available upon request)
LED: Lumileds
CRI: 80
CCT: 3000K, 4000K
Total Power Consumption (W): 40 (other wattages available)
Electrical Protection: Class 1 default/ Class 11
Control Options
Standard: Non dimmable
Dimming upon request: Smart Control Available, DALI
Mounting Options
Standard: 76mm Standard
